Dimondek® 300

Standard Colours

For Designer, Metallic and Gloss colours, download the ColorCote® special colours brochure.

Black
Minimum Pitch
Rib type
Concealed Clip
Ribs per sheet
3
Width
305 cover
310 sheet
Suitable for
Light Commercial
Commercial
Manufactured in
Hamilton
Terms & Conditions

Dimondek ® 300 Performance






Dimondek 300 is a concealed clip profile, perfect for projects where fine detail and design proportions are paramount. Suitable for low pitch roofs, the stiffened ribs provide additional strength. A concealed clip system means no penetrations through the roof, greatly reducing the risk of leaks to the building.

Cover (mm)
Sheet width (mm)
Minimum Pitch
Cover (mm)
305
Sheet width (mm)
310
Minimum Pitch
3º (approx. 1:20)

All dimensions given are nominal

Sheet Tolerances
Sheet width: ±5mm
Sheet length: +10mm, –0mm. For horizontal wall cladding where notified at time of order of intended use, tighter tolerances can be achieved +3mm, –0mm.

Material Options Thickness (BMT)
Steel 0.55mm
Steel 0.75mm
Aluminium 0.90mm
Copper 0.55mm
Nominal weight/lineal metre (kg/m)
Steel 0.55mm
2.31
Steel 0.75mm
3.12
Aluminium 0.90mm
1.24
Copper 0.55mm
2.50
Drape curved roof - min. radius (m)
Steel 0.55mm
n/r
Steel 0.75mm
n/r
Aluminium 0.90mm
n/r
Copper 0.55mm
n/r
Purlin spacings for drape curved roof (m)(1)
Steel 0.55mm
n/r
Steel 0.75mm
n/r
Aluminium 0.90mm
n/r
Copper 0.55mm
n/r
Machine crimp curved - roof min. radius (mm)
Steel 0.55mm
n/a
Steel 0.75mm
n/a
Aluminium 0.90mm
n/a
Copper 0.55mm
n/a
Unsupported overhang (2)(mm)
Steel 0.55mm
250
Steel 0.75mm
350
Aluminium 0.90mm
200
Copper 0.55mm
200

*Dimondek 300 is available in Copper ex Auckland only, subject to coil availability.

(1) Recommended maximum purlin spacing at minimum radius

(2) Based on 1.1kN point load support, but not intended for roof access.

n/r – not recommended

n/a – not available

Roll-forming facilities for Dimondek® 300 at: Hamilton


Sheet lengths:
Dimondek® 300 is custom run to order.


Where long sheets are used consideration must be given to:

  • Special transportation licences for sheet lengths over 25m
  • Site access for special lifting equipment
  • Fixing techniques to accommodate thermal expansion.

Refer Section 2.1.3.4 of Technical Manual.

DD300 Limit State Load / Span Capacity

(span in mm, distributed ultimate loads in kPa)

Non-Access
Unrestricted Access / Roof
Restricted Access / Roof
Non-Access / Roof or Wall
Unrestricted Access / Roof
End Span
Internal Span
Ultimate^
End Span
900
Internal Span
1400
Ultimate^
2.2
Restricted Access / Roof
End Span
1000
1100
1300
Internal Span
1500
1700
2000
Ultimate^
2.2
2.2
1.9
Non-Access / Roof or Wall
End Span
1400
1600
Internal Span
2100
2400
Ultimate^
1.7
1.3
G300 Steel 0.75mm
Unrestricted Access / Roof
Restricted Access / Roof
Non-Access / Roof or Wall
Unrestricted Access / Roof
End Span
Internal Span
Ultimate^
End Span
1100
Internal Span
1600
Ultimate^
2.2
Restricted Access / Roof
End Span
1100
1300
1500
Internal Span
1700
2000
2300
Ultimate^
2.2
2.2
2.1
Non-Access / Roof or Wall
End Span
1600
1900
Internal Span
2400
2800
Ultimate^
1.9
1.2
5052 H36 Aluminium 0.90mm
Unrestricted Access / Roof
Restricted Access / Roof
Non-Access / Roof or Wall
Unrestricted Access / Roof
End Span
Internal Span
Ultimate^
End Span
800
Internal Span
1100
Ultimate^
2.2
Restricted Access / Roof
End Span
900
1100
Internal Span
1200
1400
1600
Ultimate^
2.2
2.1
1.9
Non-Access / Roof or Wall
End Span
800
1700
Internal Span
1700
2000
Ultimate^
1.8
1.3
1/2 hard Copper 0.55mm
Unrestricted Access / Roof
Restricted Access / Roof
Non-Access / Roof or Wall
Unrestricted Access / Roof
End Span
Internal Span
Ultimate^
End Span
600
Internal Span
1100
Ultimate^
2.2
Restricted Access / Roof
End Span
800
110
Internal Span
1300
1500
1800
Ultimate^
2.2
2.2
1.9
Non-Access / Roof or Wall
End Span
1200
1500
Internal Span
1900
2000
Ultimate^
1.7
1.2

*Subject to availability
^ See point 5 in notes

Notes
  1. In any category, spans above the maximum shown should not be used. Category 1 and 2 maximum spans are based on static point load testing as a guide, and further limited by practical experience of roof performance under dynamic foot traffic loads. Category 3 maximum spans are limited as a guide to achieving satisfactory appearance for wall cladding.
  2. Loads given are based on clip fastening every rib at every purlin.
  3. Loads given are limited to a maximum of 2.2 kPa U.L.S. If design requirements exceed this limit, the push on Dimond wind clamps can be installed to double the wind uplift load.
  4. N/R = not recommended.
  5. For the purposes of serviceability design, the serviceability limit, limited by permanent rib deformation, occurs essentially at the same load as ultimate failure which is the point of disengagement of the roof with the clip.
  6. End span capacities given in this table are based on the end span being 2/3 of the internal span.
  7. Design Criteria for Limit State Capacities
    1. Serviceability Limit State
      No deflection or permanent distortion that would cause unacceptable appearance, side lap leakage or water ponding, due to foot traffic point loads, inward or outward wind loads or snow loads.
    2. Ultimate Limit State
      No pull through of fixings or fastener withdrawal resulting in sheet detachment due to wind up-lift (outward) loads.
  8. System Design
    The span capacity of Dimondek® 300 is determined from the Dimondek® 300 Limit State Load/Span Capacity Chart using the section of the chart appropriate to the grade and type of material, and to the category of serviceability selected from the three categories below. It is recommended that to obtain a dependable design strength capacity for the ultimate limit state, a reduction factor of Ø = 0.8 is applied.
    The capacities given do not apply for cyclonic wind conditions
  9. Serviceability Requirements
    While these categories are given for design guidance to meet the serviceability limit state criteria, foot traffic point load damage may still occur if there is careless placement of these point loads.

    Unrestricted-access roof

    Expect regular foot traffic to access the roof for maintenance work and able to walk anywhere on the roof. No congregation of foot traffic expected.
    Restricted-access roof

    Expect occasional foot traffic educated to walk only on the purlin lines, in the profile pans, or carefully across two profile ribs.
    Walkways installed where regular traffic is expected, and “Restricted Access” signs placed at access points.
    Non-access roof or wall

    Walls or roofs where no foot traffic access is possible or permitted. If necessary, “No Roof Access” signs used.

  10. Wind Pressure Guide
    As a guide for non-specific design the following S.L.S. design loads in accordance with the MRM Roofing Code of Practice can be used for buildings less than 10m high, otherwise AS/NZS 1170.2 should be used.
    Low wind zone = 0.68kPa, Medium wind zone = 0.93kPa, High wind zone = 1.32kPa, Very high wind zone = 1.72kPa and Extra high wind zone = 2.09kPa.

DD300 Fastener Design



Dimondek® 300 is clip-fastened to either timber or steel purlins. The use of the appropriate type and length of fastener for clip fixing will ensure failure by fastener pull out will not occur under loads within the scope of the Limit State Load / Span Capacity Chart.

Purlin Type
Clip Fastener
Timber
Clip Fastener
10g x 45mm timbertite wafer head screw or T17 M4x75mm pan head for fixing through Cavibats and 17.5mm thick ply
Steel
Clip Fastener
10g x 16mm wafer head screw

*If sarking or insulation is used over the purlins or for wall cladding fixing onto a cavity batten, into the stud, the screw length will need to be increased.

For screw size range refer Section 2.2.3.1 of Technical Manual.

The Limit State Load / Span Capacity Chart is based on every rib being clip fastened to every purlin or girt.



Design Example



Restricted access roof, 0.55mm G300 steel Dimondek® 300 has a maximum end span of 1300mm and a maximum internal span of 2000mm. The following distributed load capacities apply.

End Span
Internal Span
Ultimate Span
1300mm
Internal Span
2000mm
Ultimate Span
1.9 kPa
